Commerical 2MW 5MW Container Solar Battery Energy Storage

AS5MW Energy Storage Container

Product categories

how can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

Container Energy Storage System
Rated output power		5MWh(0.5C)	2.5MWh(0.5C)
Rated capacity		3.2V28OAH CELL/51.2V28OAH module
AC Phases		Three-phase Four-wire
Grid discharge mode	Rated voltage	380V
	Voltage range	380±15%V
	Rated frequency	50Hz
	Frequency range	475～51.5Hz
	Total current waveform	<5%
	distortion rate(THD)	<5%
	Output power factor	20.99
Off-grid operation mode	Rated voltage	380V
	Voltage accuracy	<±3%
	Output voltage distortion	<5%
	Rated output frequency	50±2%Hz
	Voltage transition range	<10%
	Can withstand three - phase load imbalance	100%
Grid-connected charging operation mode	Rated yoltage	400V
	Voltage range is allowed	380±15%V
	Frequency range	475~51.5HZ
	Power factor	20.99(absolute value)
Noise		<70dB
IP GRADE		IP54
External communication		Ethernet
Customized Container		Fire Extinguisher/Lighting system/Air conditioner (Water cooling system optional/Anti fire Layer etc)
Dimension		40'HQ	20'HQ
Weight		~70TON	~30TON
Cooling method		Air conditioner/Liquid cooling
Certification		CE/MSDS/UN38.3/UL/IEC62619/VDE4110
