AS420-440M10-108 Bifacial
| Cell | N-type TOPCon Mono |
| No.of cells | 108(6x18) |
| Cable Length | 300mm(+)/300mm(-) |
|
Cable Cross Section Size
|
4mm²(IEC)
|
|
Junction Box
|
IP68
|
|
Connector
|
MC4 Compatible
|
|
Weight
|
24.2kgs±3%
|
|
Cells Type
|
Mono 182x91mm
|
|
Dimension(LxWxT)
|
1722±2mmx1134±2mmx30/35±1mm
|
|
Packaging
|
36pcs/pallet,360pcs/20GP;936pcs/40HQ(30mm) 31pcs/pallet,306pcs/20GP;806pcs/40HQ(35mm)
|
420W-440W Half Cells Mono Solar Panel China Factory that's grade A quality for ensuring stable performance and 25 years output guarantee.
Our solar modules can be used on on-grid solar sytem, hybrid solar system, off-grid solar system, and all kinds of solar applicatons... and worked with lithium battery ( solar lithium ion battery ), lead-acid battery (Lead-Acid Deep Cycle Battery), solar inverters, mounting structure, ...for residential project, comercial projects and big unitlity projects.
| Module Type | AS420M10-108 | AS425M10-108 | AS430M10-108 | AS435M10-108 | AS440M10-108 |
| Maximum Power(Pmax/W) | 420 | 425 | 430 | 435 | 440 |
| Open Circuit Voltage(Voc/V) | 39.41 | 39.53 | 39.65 | 39.77 | 39.89 |
| Short Circuit Current(Isc/A) | 13.53 | 13.59 | 13.65 | 13.71 | 13.71 |
| Voltage at Maximum Power(Vmp/V) | 31.85 | 32.05 | 32.25 | 32.45 | 32.65 |
| Current at Maximum Power(Imp/A) | 13.19 | 13.27 | 13.34 | 13.41 | 13.48 |
| Module Efficiency(%) | 21.51 | 21.76 | 22.02 | 22.30 | 22.53 |
AS410-430M10-108 Bifacial Cell N-type TOPCon Mono No.of cells 108(6x18) Cable Length 300mm(+)/300mm(-) Cable Cross Section Size 4mm²(IEC) Junction Box IP68 Connector MC4 Compatible Weight 24.2kgs±3% Cells Type Mono 182x91mm Dimension(LxWxT) 1722±2mmx1134±2mmx30/35±1mm Packaging 36pcs/pallet,360pcs/20GP;936pcs/40HQ(30mm) 31pcs/pallet,306pcs/20GP;806pcs/40HQ(35mm)
Learn More
AS425-450M10-108 Bifacial Cell N-type TOPCon Mono No.of cells 108(6x18) Cable Length 300mm(+)/300mm(-) Cable Cross Section Size 4mm²(IEC) Junction Box IP68 Connector MC4 Compatible Weight 24.2kgs±3% Cells Type Mono 182x91mm Dimension(LxWxT) 1722±2mmx1134±2mmx30/35±1mm Packaging 36pcs/pallet,360pcs/20GP;936pcs/40HQ(30mm) 31pcs/pallet,306pcs/20GP;806pcs/40HQ(35mm)
Learn More
Amosolar 200KW PV Solution Name Storage 200KW System Warranty 25 Years Output Power Guarantee Certificate TUV/IEC/CEC/CE/ISO/Inmetro Application Home/Business Output Voltage EU:220/230/240V ; 380/400V Monitoring Wifi/GPRS Mounting Brackets Roof/Ground installation
Learn More
TSM-NEG21C.20 675-700W Cell Arrangement 132 Junction Box IP68 rated Weight 38.3KG Cable Length 350/280mm Cable Size 4 mm2 (IEC) PV Size 2384 x1303x 35 mm Packaging 33 pcs/ pallet 594pcs/40HQ container
Learn More
Amosolar 10KW 12KW 15KW ON Grid Solar System Name ON Grid 10KW System Warranty 25 Years Output Power Guarantee Certificate TUV/IEC/CEC/CE/ISO/Inmetro Application Home/Business Output Voltage EU:220/230/240V;380V/400V Monitoring Wifi/GPRS Mounting Brackets Roof/Ground installation
Learn More
AS51100W/AS51200W Amosolar lithium battery:6000 Cycles, 10 Years+ design life,TUV CE EN62619 IEC 62040 UN38.3 CEC,Built-in BMS. Model Number AS51100W/AS51200W Capacity(Ah) 100/200 Nominal Voltage 51.2V Weight( Approx) (KG) 54.5kg/88.45kg Dimension(W/D/H)(mm) 485*690*226mm Battery Type LiFePo4(LFP) Cycle Life 6000 Cycles
Learn More
ESS-100230 ESS HV 100KW 230KW Energy Storage System Manufacturer Battery System For Commercial And Industrial. Brand Amosolar Type ESS Max.Power 100-230kW
Learn More
AMO 10.24K-20.48K_LV-T1 Amosolar Low-voltage lithium battery:6000 Cycles,TUV CE EN62619 IEC 62040 UN38.3 CEC,Built-in BMS. Model Number AMO 10.24K_LV-T1 AMO 15.36K_LV-T1 AMO 20.48K_LV-T1 Capacity(Ah) 200Ah 300Ah 400Ah Maximum Nominal Voltage 51.2V Energy(Kwh) 10.24~20.48Kwh Charge Temperature(℃) 0~55℃ DisCharge Temperature(℃) -20~55℃ Cycle Life 6000 Cycles
Learn More
