AS-600/800BL
|
Model Number |
AS-600/800BL |
|
Load Power
|
600W,800W |
|
Peak Efficiency
|
97.1%/97.3% |
|
Certificates
|
CE/TUV/ISO/CQC/MCS/INMETRO/IEC
|
|
Warranty
|
10Years
|
600W 800W Balcony Solar System Full Black
Generate your own energy,Saving electricity bill,Rapid shutdown function,More effective, Max. Efficiency 97.1%,More secure: Built-in grounding Lightning,protection 6000V,More Reliability
| Input Data (DC) | ||||
| Inverter power | 600W | 800W | ||
| Recommended input Power(STC) | Full Black 410W (PERC) *2 | Full Black 430W (N-TOPCON) *2 | Full Black 460W (PERC) *2 | Full Black 510W (N-TOPCON) *2 |
| Maximum input DC Voltage | 60V | |||
| Startup Voltage | 24V | |||
| MPPT Voltage Range | 22-55 | |||
| Maximum input DC Current | 18A | |||
| Output Data (AC) | ||||
| Rated output Power | 600w | 800W | ||
| Rated output Current | 2.52 | 3.26 | ||
| Rated Output Voltage /V | 220/230v，L+N+PE | |||
| Output Frequency Range | 50 / 60Hz | |||
| Power Factor (Nominal/Adjustable Range) | 1.0/0.8 leading…0.8 lagging | |||
| Output Current Total Harmonic Distortion | <3% | |||
| Efficiency | ||||
| Peak Efficiency | 97.1% | 97.3% | ||
| MPPT Efficiency | >99.5% | >99.5% | ||
| Night Power Consumption /MW | <100 | <100 | ||
| Mechanical Data | ||||
| Operating Ambient Temperature Range | '-40°C ~+65°C | |||
| Microinverter Dimensions (W x H x D) /MM | 227 x 132 x 50 | |||
| Microinverter Weight | 2.9kg | |||
| Cooling | Natural convection-No fans | |||
| Protection Class | NEMA-6 / IP-66 / IP-67 | |||
| Overvoltage class | III | |||
| Features | ||||
| Noise | ＜10db | |||
| Communication | PLC or WiFi | |||
| System Integration | Integration of System and Module | |||
| Certificates | CE,EMC,RED,ROHS,EN50549,VDE-0126,VDE-4105,VDE-0124,CEI-021,UL1741,CSA22.2,CEC,AS 4777 | |||
| Warranty | 10 years | |||
AS-600/800BL Model Number AS-600/800BL Load Power 600W,800W Peak Efficiency 97.1%/97.3% Certificates CE/TUV/ISO/CQC/MCS/INMETRO/IEC Warranty 10Years
Learn More
JAM66D42 MB 570-595W Cell Arrangement 132(6 X 22) Junction Box IP68, 3 diodes Weight 31.8KG Cable Length +400,-200mm/±1400mm Cable Size 4 mm2 (lEC) PV Size 2278 X1134X30mm Packaging 36 pcs/pallet 720pcs/40HQ container
Learn More
CS3W-435-465MS Cell Arrangement 144 [2 X(12 X 6) Junction Box IP68, 3 bypass diodes Weight 24.3KG Cable Length 500 mm (19.7 in)(+)/350 mm (13.8 in) (-) Cable Size 4 mm2 (lEC), 12 AWG (UL) PV Size 2108 X1048 X35 mm Packaging 30 pcs/pallet 660pcs/40HQ container
Learn More
TSM-NEG9RC.27 415-445W Cell Arrangement 144 (24 X 6) Junction Box IP68 rated Weight 21.0KG Cable Length N 280mm/P 280mm Cable Size 4 mm2 PV Size 1762 x1134x 30mm Packaging 36 pcs/pallet 936pcs/40HQ container
Learn More
JKM445-470N-48HL4M-BDV-Z1-EN Cell Arrangement 96 (2 X48) Cell Type N- type Mono-crystalline Weight 24KG Junction Box IP68 Rated Protection Class Class II Pallet Dimensions 1792X1140x1249mm Packaging 37 pcs/pallets, 74 pcs/stack, 962 pcs/ 40'HQ Container
Learn More
JKM570-590N-72HL4-(V)-F7-EN Cell Arrangement 144 (2 X72) Junction Box IP68, 3 bypass diodes Weight 27.0KG Cable Length 500mm (19.7 in)(+)/350 mm (13.8 in) (-) Cable Size 4mm2 (IEC), 12 AWG (UL) PV Size 2278X1134x30mm Packaging 36pcs/pallet 720pcs/40HQ container
Learn More
AS5MW Energy Storage Container Place of Origin Anhui, China Brand Name Amosolar BatteryType LiFePO4 Dimension (L*W*H) 12192*2438*2896mm Weight ~30TON ~70TON Communication Interface CAN
Learn More
JAM54D40 430-455/LB Cell Arrangement 108(6 X18) Junction Box IP68, 3 diodes Weight 22KG Cable Length 300mm(+)/400mm(-) Cable Size 4 mm2 (lEC), 12 AWG (UL) PV Size 1762X1134X30mm Packaging 36 pcs/pallet 936pcs/40HQ container
Learn More
