| Cell Arrangement | 96 (2 X48) |
| Cell Type | N- type Mono-crystalline |
| Weight | 24KG |
| Junction Box | IP68 Rated |
| Protection Class | Class II |
| Pallet Dimensions | 1792X1140x1249mm |
| Packaging | 37 pcs/pallets, 74 pcs/stack, 962 pcs/ 40'HQ Container |
Electrical Performance Parameters (STC Test)
| Maximum Power - Pmax [Wp] | 445 | 450 | 455 | 460 | 465 | 470 |
| Maximum Power Voltage - Vmp [V] | 30.30 | 30.53 | 30.77 | 31.00 | 31.23 | 31.46 |
| Maximum Power Current - Imp [A] | 14.69 | 14.74 | 14.79 | 14.84 | 14.89 | 14.94 |
| Open-circuit Voltage - Voc [V] | 36.02 | 36.19 | 36.36 | 36.53 | 36.70 | 36.87 |
| Short-circuit Current - Isc [A] | 15.60 | 15.65 | 15.70 | 15.75 | 15.80 | 15.85 |
| Module Efficiency STC [%] | 22.27 | 22.52 | 22.77 | 23.02 | 23.27 | 23.52 |
| Power Tolerance | 0 ~ +3% | |||||
| Temperature Coefficients of Pmax | -0.29 %/°C | |||||
| Temperature Coefficients of Voc | -0.25 %/°C | |||||
| Temperature Coefficients of Isc | 0.045 %/°C | |||||
CS3W-435-465MS Cell Arrangement 144 [2 X(12 X 6) Junction Box IP68, 3 bypass diodes Weight 24.3KG Cable Length 500 mm (19.7 in)(+)/350 mm (13.8 in) (-) Cable Size 4 mm2 (lEC), 12 AWG (UL) PV Size 2108 X1048 X35 mm Packaging 30 pcs/pallet 660pcs/40HQ container
Learn More
CS6W-530-555MS Cell Arrangement 120 [2 X (10 X 6)] Junction Box IP68, 3 bypass diodes Weight 31.0KG Cable Length 460 mm (18.1 in)(+)/340 mm (13.4 in) (-) Cable Size 4 mm2 (IEC), 12 AWG (UL) PV Size 2172 X1303 X35 mm Packaging 31 pcs/pallet 527pcs/40HQ container
Learn More
CS6W-530-555MS Cell Arrangement 144 [2X(12 X6)] Junction Box IP68, 3 bypass diodes Weight 27.6KG Cable Length 410 mm (16.1 in) (+)/ 290 mm (11.4 in)(-) Cable Size 4 mm2 (IEC), 12 AWG (UL) PV Size 2261 X 1134 X30 mm Packaging 35pcs/pallet 700pcs /40HQ container
Learn More
JAM54D41 430-455/LB Cell Arrangement 108 (6 X18) Junction Box IP68, 3 diodes Weight 22KG Cable Length 300mm(+)/400mm(-) Cable Size 4 mm2 (IEC), 12 AWG (UL) PV Size 1762X1134X30 mm Packaging 36 pcs/pallet 936pcs/40HQ container
Learn More
JAM72D42 615-640W/LB Cell Arrangement 144(6 X 24) Junction Box IP68, 3 diodes Weight 34.6KG Cable Length 300mm(+)/400mm(-) Cable Size 4 mm2 (IEC), 12 AWG (UL) PV Size 2465 X1052X35 mm Packaging 36 pcs/pallet 576pcs/40HQ container
Learn More
TSM-NEG9RC.27 415-445W Cell Arrangement 144 (24 X 6) Junction Box IP68 rated Weight 21.0KG Cable Length N 280mm/P 280mm Cable Size 4 mm2 PV Size 1762 x1134x 30mm Packaging 36 pcs/pallet 936pcs/40HQ container
Learn More
TSM-NEG19RC.20 580-605W Cell Arrangement 150 Junction Box IP68 rated Weight 33.7KG Cable Length N 280mm/P 280mm Cable Size 4 mm2 (IEC) PV Size 2384x1134x30 mm Packaging 36 pcs/pallet 720pcs/40HQ container
Learn More
TSM-NEG21C.20 675-700W Cell Arrangement 132 Junction Box IP68 rated Weight 38.3KG Cable Length 350/280mm Cable Size 4 mm2 (IEC) PV Size 2384 x1303x 35 mm Packaging 33 pcs/ pallet 594pcs/40HQ container
Learn More
