645W 650W 655W 660W 665W 670W 675W Bifacial Double Glass Half Cells Mono Solar Panel China Factory

AS645-675G12-132B

Amosolar soalr panel :High Efficiency,Grade A Quality,Factory Price.

Cell Mono
Rated Maximum Power
675W
Maximum Efficiency 21.7%
Weight
38.7kgs±3%
Cells Type
Mono 210x105mm
Dimension(LxWxT)
2384±2mmx1303±2mmx35±1mm
Packaging
31pcs/pallet, 558pcs/40HQ container

645W-675W Bifacial Double Glass Half Cells Mono Solar Panel China Factory : 132 half cut solar cell MBB A grade PV Modules from Chinese manufactory.

Monocrystalline Solar Panel 500W



Electrical Performance Parameters (STC Test)


Model
AS645G12-132B AS645G12-132B
AS645G12-132B
AS645G12-132B
AS645G12-132B
AS645G12-132B
AS645G12-132B
Rated Maximum Power at STC 645W
650W 655W 660W 665W 670W 675W
Open Circuit Voltage (Voc) 45.0 45.2 45.4 45.6 45.8 46.0 46.2
Maximum Power Voltage (Vmp) 37.2 37.4 37.6 37.8 38.0 38.2 38.4
Short Circuit Current (Isc) 18.41 18.46 18.50 18.55 18.60 18.65 18.70
Maximum Power Current (Imp) 17.34 17.38 17.42 17.46 17.50 17.54 17.58
PV Module Efficiency (%) 20.70 20.90 21.00 21.20 21.40 21.50 21.70
Standard Inradiance 1000w/m² , Cell Temperature 25 ℃ , Air Mass 1.5


Mechanical Parameters


Solar Panel Half Cut

  Layout :                  132( 6 × 22 )


  Junction Box :        Split junction box, IP68, 3 diodes

  Weight:                   38.7KG


  Cable Length :        300mm (+) / 300mm(-)

  Cable  Size :            4mm²(IEC)


  PV Size:                   2384×1303×35mm

  Packaging:              31 pcs / pallet

                                   558 pcs / 40HQ container
