270W 275W 280W 285W 290W 295W Poly Solar Panel Chinese Manufacturer

Polycrystalline Solar Panels
Polycrystalline Solar Panels
Polycrystalline Solar Panels
Polycrystalline Solar Panels
Polycrystalline Solar Panels

270W 275W 280W 285W 290W 295W Poly Solar Panel Chinese Manufacturer

AS270-295P-60


Cell Poly
Rated Maximum Power
295W
Maximum Efficiency 18.13%
Junction Box IP 67
Maximum System Voltage 1000V/1500V DC
Operating Temperature -40℃ ~ +85℃
Connectors MC4 EVO2/QC4.10-35

270W-295W Full Cell Polycrystalline PV Panel Chinese Manufactory : High effiency solar panels.



Electrical Performance Parameters (STC Test)


Model
AS270P-60

AS275P-60

AS280P-60
AS285P-60
AS290P-60
AS295P-60
Rated Maximum Power at STC 270W
275W 280W 285W 290W 295W
Open Circuit Voltage (Voc) 38.82 39.47 40.05 40.38 40.66 41.19
Maximum Power Voltage (Vmp) 31.70 31.93 32.22 32.61 32.95 33.22
Short Circuit Current (Isc) 9.25 9.29 9.32 9.41 9.51 9.58
Maximum Power Current (Imp)

8.52

8.61 8.69 8.74 8.8 8.88
PV Module Efficiency (%) 16.60 16.90 17.21 17.52 17.83 18.13
Standard Inradiance 1000w/m² , Cell Temperature 25 ℃ , Air Mass 1.5



Mechanical Parameters


Solar Panel Monocrystalline Price

  Layout :                  60( 6 × 10 )


  Junction Box :        Split junction box, IP67, 3 diodes

  Weight:                   17.5KG


  Cable Length :        300mm (+) / 300mm(-)

  Cable  Size :            4mm²(IEC)


  PV Size:                   1640×992×35mm

  Packaging:              31 pcs / pallet

                                938 pcs / 40HQ container

                               31 pcs / pallet

                                372 pcs / 20GQ container


Factory For Solar Panel


· Question 1: What kind of Solar Cells we have?

Answer 1:Mono solar cell, such as 158.75*158.75mm, 166*166mm, 182*182mm, 210*210mm, Poly solar cell 156.75*156.75mm.


· Question 2: What is the lead time?

Answer 2:Normally 15 working days after advance payment.


· Question 3: What is your monthly capacity?

Answer 3:Monthly capacity is about 200MW.


· Question 4:What is the warranty period, how many years?

Answer 4: 12years product warranty, 25years 80% power output warranty for monofacial solar panel, 30years 80% power output warranty for bifacial solar panel.


· Question 5: How is your technical support?

Answer 5: We provide lifetime online support through Whatsapp/ Skype/ Wechat/ Email. Any problem after delivery, we will offer you video call anytime, our engineer will also go to oversea help our customers if necessary.
