AS645-675G12-132
| Cell | Mono |
|
Rated Maximum Power |
675W |
| Maximum Efficiency | 21.73% |
| Weight | 35.7kgs±3% |
| Cells Type | Mono 210x105mm |
| Dimension (LxW×T) | 2384±2mmx1303±2mmx35±1mm |
| Packaging | 31pcs/pallet, 558pcs/40HQ container |
645W-675W Half Cut Mono PV Panel Chinese Manufactory : With multi-busbar PERC cells, 210mm solar cells will bring extraordinary product performance, wider application conditions , reliability quality and higgest safety.
Electrical Performance Parameters (STC Test)
|
Model |
AS645G12-132 |
AS650G12-132 |
AS655G12-132 |
AS660G12-132 |
AS665G12-132 |
AS670G12-132 |
AS675G12-132 |
| Rated Maximum Power at STC |
645W |
650W | 655W | 660W | 665W | 670W |
675W |
| Open Circuit Voltage (Voc) | 45.00 | 45.20 | 45.40 | 45.60 | 45.80 | 46.00 | 46.20 |
| Maximum Power Voltage (Vmp) | 37.30 | 37.50 | 37.70 | 37.90 | 38.10 | 38.30 | 38.50 |
| Short Circuit Current (Isc) | 18.31 | 18.35 | 18.39 | 18.44 | 18.48 | 18.51 | 18.55 |
| Maximum Power Current (Imp) | 17.29 | 17.33 | 17.37 | 17.41 | 17.45 | 17.49 | 17.53 |
| PV Module Efficiency (%) | 20.76 | 20.92 | 21.09 | 21.25 | 21.41 | 21.57 | 21.73 |
| Standard |
Inradiance 1000w/m² ， Cell Temperature 25 ℃ ， Air Mass 1.5 |
||||||
Mechanical Parameters
Layout : 132( 6 × 22 ）
Weight: 35.7KG
Cable Size : 4mm²（IEC)
Packaging: 31 pcs / pallet
558 pcs / 40HQ container
AS370-395M6-120 Cell Mono Rated Maximum Power 395W Maximum Efficiency 21.65% Weight 20.5kgs±3% Cells Type Mono 166x83mm Dimension(LxWxT) 1756±2mmx1039±2mmx35±1mm Packaging 31pcs/pallet, 858pcs/40HQ container
Learn More
AS380-410M10-108 Cell Mono Rated Maximum Power 410W Maximum Efficiency 21.00% Weight 21.0kgs±3% Cells Type Mono 182x91mm Dimension(LxWxT) 1722±2mmx1134±2mmx30±1mm Packaging 36pcs/pallet, 936pcs/40HQ container
Learn More
AS480-505M10-132 Cell Mono Rated Maximum Power 505W Maximum Efficiency 21.30% Weight 26.0kgs±3% Cells Type Mono 182x91mm Dimension(LxWxT) 2094±2mmx1134±2mmx35±1mm Packaging 31pcs/pallet, 682pcs/40HQ container
Learn More
AS525-550M10-144 Cell Mono Rated Maximum Power 550W Maximum Efficiency 21.28% Weight 28.6kgs±3% Cells Type Mono 182x91mm Dimension(LxWxT) 2279±2mmx1134±2mmx35±1mm Packaging 31pcs/pallet, 620pcs/40HQ container
Learn More
AS525-550M10-144 Cell Mono Rated Maximum Power 550W Maximum Efficiency 21.28% Weight 28.6kgs±3% Cells Type Mono 182x91mm Dimension(LxWxT) 2279±2mmx1134±2mmx35±1mm Packaging 31pcs/pallet, 620pcs/40HQ container
Learn More
AS580-610G12-120 Cell Mono Rated Maximum Power 610W Maximum Efficiency 21.60% Weight 30.9kgs±3% Cells Type Mono 210x105mm Dimension (LxW×T) 2172±2mmx1303±2mmx35±1mm Packaging 31pcs/pallet, 558pcs/40HQ container
Learn More
AS270-295P-60 Cell Poly Rated Maximum Power 295W Maximum Efficiency 18.13% Junction Box IP 67 Maximum System Voltage 1000V/1500V DC Operating Temperature -40℃ ~ +85℃ Connectors MC4 EVO2/QC4.10-35
Learn More
AS330-355P-72 Cell Poly Rated Maximum Power 355W Maximum Efficiency 18.30% Junction Box IP 67 Maximum System Voltage 1000V/1500V DC Operating Temperature -40℃ ~ +85℃ Connectors MC4 EVO2/QC4.10-35
Learn More
