| Cell Type | N-Type Mono-crystalline |
| No.of Cell | 132 (2X66) |
| Junction Box | IP68, Rated |
| Weight | 37.5KG |
| Frame | Anodized Aluminium Alloy |
| Protection Class | Class II |
| PV Size | 2382X1134X30mm |
| Packaging | 33pcs/pallet 594pcs/40HQ container |
Electrical Performance Parameters (STC Test)
| Maximum Power - Pmax [Wp] | 695 | 700 | 705 | 710 | 715 | 720 |
| Maximum Power Voltage - Vmp [V] | 40.29 | 40.42 | 40.53 | 40.65 | 40.77 | 40.89 |
| Maximum Power Current - Imp [A] | 17.25 | 17.32 | 17.40 | 17.47 | 17.54 | 17.61 |
| Open-circuit Voltage - Voc [V] | 48.24 | 48.40 | 48.56 | 48.73 | 48.88 | 49.04 |
| Short-circuit Current - Isc [A] | 18.33 | 18.40 | 18.46 | 18.53 | 18.60 | 18.67 |
| Module Efficiency STC [%] | 22.4 | 22.5 | 22.7 | 22.9 | 23.0 | 23.2 |
| Power Tolerance | 0 ~ +3% | |||||
| Temperature Coefficients of Pmax | -0.29 %/°C | |||||
| Temperature Coefficients of Voc | -0.25 %/°C | |||||
| Temperature Coefficients of Isc | 0.045 %/°C | |||||
CS3W-435-465MS Cell Arrangement 144 [2 X(12 X 6) Junction Box IP68, 3 bypass diodes Weight 24.3KG Cable Length 500 mm (19.7 in)(+)/350 mm (13.8 in) (-) Cable Size 4 mm2 (lEC), 12 AWG (UL) PV Size 2108 X1048 X35 mm Packaging 30 pcs/pallet 660pcs/40HQ container
Learn More
CS6W-530-555MS Cell Arrangement 120 [2 X (10 X 6)] Junction Box IP68, 3 bypass diodes Weight 31.0KG Cable Length 460 mm (18.1 in)(+)/340 mm (13.4 in) (-) Cable Size 4 mm2 (IEC), 12 AWG (UL) PV Size 2172 X1303 X35 mm Packaging 31 pcs/pallet 527pcs/40HQ container
Learn More
CS6W-530-555MS Cell Arrangement 144 [2X(12 X6)] Junction Box IP68, 3 bypass diodes Weight 27.6KG Cable Length 410 mm (16.1 in) (+)/ 290 mm (11.4 in)(-) Cable Size 4 mm2 (IEC), 12 AWG (UL) PV Size 2261 X 1134 X30 mm Packaging 35pcs/pallet 700pcs /40HQ container
Learn More
JAM54D41 430-455/LB Cell Arrangement 108 (6 X18) Junction Box IP68, 3 diodes Weight 22KG Cable Length 300mm(+)/400mm(-) Cable Size 4 mm2 (IEC), 12 AWG (UL) PV Size 1762X1134X30 mm Packaging 36 pcs/pallet 936pcs/40HQ container
Learn More
JAM72D42 615-640W/LB Cell Arrangement 144(6 X 24) Junction Box IP68, 3 diodes Weight 34.6KG Cable Length 300mm(+)/400mm(-) Cable Size 4 mm2 (IEC), 12 AWG (UL) PV Size 2465 X1052X35 mm Packaging 36 pcs/pallet 576pcs/40HQ container
Learn More
TSM-NEG9RC.27 415-445W Cell Arrangement 144 (24 X 6) Junction Box IP68 rated Weight 21.0KG Cable Length N 280mm/P 280mm Cable Size 4 mm2 PV Size 1762 x1134x 30mm Packaging 36 pcs/pallet 936pcs/40HQ container
Learn More
TSM-NEG19RC.20 580-605W Cell Arrangement 150 Junction Box IP68 rated Weight 33.7KG Cable Length N 280mm/P 280mm Cable Size 4 mm2 (IEC) PV Size 2384x1134x30 mm Packaging 36 pcs/pallet 720pcs/40HQ container
Learn More
TSM-NEG21C.20 675-700W Cell Arrangement 132 Junction Box IP68 rated Weight 38.3KG Cable Length 350/280mm Cable Size 4 mm2 (IEC) PV Size 2384 x1303x 35 mm Packaging 33 pcs/ pallet 594pcs/40HQ container
Learn More
