AS435-455M6-144
| Cell | Mono |
| Rated Maximum Power | 465W |
| Maximum Efficiency | 20.93% |
|
Weight
|
28.1kgs±3%
|
|
Cells Type
|
Mono 166x83mm
|
|
Dimension(LxWxT)
|
2094±2mmx1038±2mmx30±1mm
|
|
Packaging
|
35pcs/pallet, 770pcs/40HQ container
|
440W-465W Bifacial Double Glass Half Cells Mono Solar Panel that's grade A quality for ensuring stable performance and 25 years output guarantee.
Our solar modules can be used on on-grid solar sytem, hybrid solar system, off-grid solar system, and all kinds of solar applicatons... and worked with lithium battery ( solar lithium ion battery ), lead-acid battery (Lead-Acid Deep Cycle Battery), solar inverters, mounting structure, ...for residential project, comercial projects and big unitlity projects.
Electrical Performance Parameters (STC Test)
| Model |
AS435M6-144B
|
AS440M6-144B | AS445M6-144B | AS450M6-144B | AS455M6-144B | |
| Rated Maximum Power at STC | 435W | 440W | 445W | 450W | 455W | |
| Open Circuit Voltage (Voc) | 48.96 | 49.16 | 49.36 | 49.56 | 49.76 | |
| Maximum Power Voltage (Vmp) | 40.81 | 41.01 | 41.21 | 41.40 | 41.59 | |
| Short Circuit Current (Isc) | 11.35 | 11.42 | 11.49 | 11.56 | 11.63 | |
| Maximum Power Current (Imp) | 10.66 | 10.73 | 10.80 | 10.87 | 10.94 | |
| PV Module Efficiency (%) | 20.01 | 20.24 | 20.47 | 20.70 | 20.93 | |
| Standard | Inradiance 1000w/m² ， Cell Temperature 25 ℃ ， Air Mass 1.5 | |||||
With multi-busbar PERC cells, the half-cell configuration of the modules offers the advantages of higher power output, better temperature-dependent performance.
AMO M6 Amosolar Portable Power Station, TUV CE UN38.3 FCC RoHS,Outdoor Adventure for campers, explorers, RV dwellers, Home&Emergency Backup for professionals,outdoor and emergency preppers. Brand Amosolar Type Portable Power Station Max.Power 600W
Learn More
JKM570-590N-72HL4-(V)-F7-EN Cell Arrangement 144 (2 X72) Junction Box IP68, 3 bypass diodes Weight 27.0KG Cable Length 500mm (19.7 in)(+)/350 mm (13.8 in) (-) Cable Size 4mm2 (IEC), 12 AWG (UL) PV Size 2278X1134x30mm Packaging 36pcs/pallet 720pcs/40HQ container
Learn More
AS415-440M10-108 Cell Mono Rated Maximum Power 440W Maximum Efficiency 22.53% Weight 21kgs±3% Cells Type Mono 182x91mm Dimension(LxWxT) 1722±2mmx1134±2mmx30±1mm Packaging 36pcs/pallet, 936pcs/40HQ container
Learn More
AS530-560M10-144 Cell Mono Rated Maximum Power 560W Maximum Efficiency 21.67% Weight 28.6kgs±3% Cells Type Mono 182x91mm Dimension(LxWxT) 2279±2mmx1134±2mmx35±1mm Packaging 31pcs/pallet, 620pcs/40HQ container
Learn More
AS515-540M10-132 Cell Mono Rated Maximum Power 540W Maximum Efficiency 22.74% Weight 24.5kgs±3% Cells Type Mono 182x91mm Dimension(LxWxT) 2094±2mmx1134±2mmx35±1m Packaging 31pcs/pallet, 682pcs/40HQ container
Learn More
AS525-550M10-144 Cell Mono Rated Maximum Power 550W Maximum Efficiency 21.28% Weight 28.6kgs±3% Cells Type Mono 182x91mm Dimension(LxWxT) 2279±2mmx1134±2mmx35±1mm Packaging 31pcs/pallet, 620pcs/40HQ container
Learn More
Amosolar 8KW 9KW 10KW Hybrid Solar System Name Hybrid 10KW System Warranty 25 Years Output Power Guarantee Certificate TUV/IEC/CEC/CE/ISO/Inmetro Application Home/Business Output Voltage EU:220/230/240V ; 380/400V Monitoring Wifi/GPRS Mounting Brackets Roof/Ground installation
Learn More
Amosolar 10KW 11KW 12KW Hybrid Solar System Name Hybrid 10KW System Warranty 25 Years Output Power Guarantee Certificate TUV/IEC/CEC/CE/ISO/Inmetro Application Home/Business Output Voltage EU:220/230/240V ; 380/400V Monitoring Wifi/GPRS Mounting Brackets Roof/Ground installation
Learn More
