Amosolar 500KW PV Solution
| Name | 500KW System |
| Warranty | 25 Years Output Power Guarantee |
| Certificate | TUV/IEC/CEC/CE/ISO/Inmetro |
| Application | Home/Business |
| Output Voltage | EU:380/400V(330-440V) |
| Monitoring | Wifi/GPRS |
| Mounting Brackets | Roof/Ground installation |
Electrical Performance Parameters (STC Test)
Mounting Structure
PV Cable
6mm² PV Cable
MC4
MC4 Connector
Standard Wooded Package + System Connecting Drawings (Easy Installing)
System Capacity could be adjustable according customer's situation
Mechanical Parameters
100KW PV Solution
Name
Description
Quantity
Solar Panel
Half Cell 550W
950 PCS
PV Combiner Box
10 ~ 20 input 1 output , (Switches,Breaker,SPD)
1-5 PCS
Inverter
500KW On Grid Solar Inverter
1 PCS
Roof/Ground Install (Customized)
1 Set
1000~2000m
100 Prs
High Efficiecy PV Module
·Higher Output Power
·Less Shading And Lower Resistive Loss
·Better Mechanical Loading
·Lower LCOE
Grid Tied Solar Inverter
·Maximum Efficiency Of 99 % , Wide Working Voltage
·String Monitoring , AC/DC Type II SPD , IP 65 Protection Rating.
·6/7 MPPTs , 400 Vac/480 Vac
·Interfaces ：RS485 / USB / WIFI / RF / GPRS
·Warranty : 10 Years +
Smart Meter
·Support RF Communication With Raillog
·Quick Plug - And - Play Installation
·Energy Manager With ShineLink
·Accessories : R5485 Cable (15m)
Solar Mounting Solutions
·Good Stability 、Good Load-Bearing Capacity And Stable Structure
·Flat Surface 、Neat Incision And Assembled Installation
·Support Customization According To Needs
·Integrated Services
·Adequate Inventory
