Amosolar PV Module 200W Monocrystalline Small Solar Panel
Products
Home / SOLAR PANEL / Small PV Module / Mono 166mm /

Amosolar PV Module 200W Monocrystalline Small Solar Panel

Mini Solar PV Module
Mini Solar PV Module
Mini Solar PV Module
Mini Solar PV Module
Mini Solar PV Module

Amosolar PV Module 200W Monocrystalline Small Solar Panel

AS200M6-64

Amosolar soalr panel :High Efficiency,Grade A Quality,Factory Price.

Cell Mono
Rated Maximum Power
 200W
Maximum Efficiency 19.01%
Junction Box IP 67
Maximum System Voltage 1000VDC
Weight
11.67kg
Solar Cells
Mono crystalline 166X83mm (4X16pcs)
Inquire Now

200W Small Monocrystalline PV Panel Chinese Manufactory :

This 200 Watt solar panel can be used for many different applications. Ground mount compatible. Compatible with on-grid and off-grid inverters. It guaranteed positive output tolerance (0-3%); withstands high winds (2400Pa) and snow loads (5400Pa). A corrosion-resistant aluminum frame allows for extended outdoor use with a typical lifespan of decades. Anti-reflective, high transparency, low iron tempered glass with enhanced stiffness and impact resistance. IP67 rated junction box provides complete protection against environmental particles and low-pressure water jets.




                    Model
 AS200M6-64
Rated Maximum Power at STC 200W
Open Circuit Voltage (Voc) 21.98
Maximum Power Voltage (Vmp) 11.28
Short Circuit Current (Isc) 19.74
Maximum Power Current (Imp) 10.13
PV Module Efficiency (%) 19.01
Standard Inradiance 1000w/m² ， Cell Temperature 25 ℃ ， Air Mass 1.5



Mechanical Parameters

Solar Panel Monocrystalline Price

  Layout :                  64( 4 × 16 ）

  Junction Box :        Split junction box, IP67

  Weight:                  11.67KG

  Cable Length :        300mm (+) / 300mm（-)

  Cable  Size :            4mm²（IEC)

  PV Size:                   1405x700x30mm

  Packaging:              36 pcs / pallet

Factory For Solar Panel


Related Tags : 166mm solar cell pv module Solar industry Small solar panel manufactory Small solar system Monocrystalline solar panels Solar panels for street light
Leave A Message
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
Subject : Amosolar PV Module 200W Monocrystalline Small Solar Panel
